Industrial Weighing

Blender Type

Loss-In-Weight Feeder is a precision feeding device designed specifically for handling granular or free-flowing powdered materials. Utilizing advanced technology, this feeder is capable of delivering maximum accuracy at minimal feed rates, meeting the precise ingredient requirements in different industries.

PRODUCT DESCRIPTION

The Blender type loss-in-weight feeder is specially designed for formula dosing, precise granular feeding demands. According to the recipe requirements, different combination of hoppers are available. Not only the appearance is beautiful, but also it is easy to install and maintain.

Main Feature

Compact and attractive appearance design, easy to install and maintain.
Suitable for precise particle feeding.
Different combinations can be selected according to recipe requirements.
Cost-effective.
Disassembled without tools.
7 inches color touch screen.
Double feedback control system

APPLICATION

It is suitable for pellets and precise particle feeding.

SPECIFICATION

ltem	Blender Type
Model	ZZL-20-SZ
Specification	H-3	H-4	H-5	H-6
Flow Rate Range (L/h)	50 - 300	80 - 600	100 - 1500	150 - 2000
Hopper Sizes (L)	15	15	20、50	20、50
Number	3	4	5	6
Weighing Range	50	50	50, 100	50, 100
Net Weight	180	250	400	460
Length (mm)	1070	1220	1220	1590
Width (mm)	890	1220	1215	1180
Height (mm)	1640	1468	1995	2100
Power Supply	AC 220 - 240 V, 50/60 Hz, 1.0 KW	AC 220 - 240 V, 50/60 Hz, 1.2 KW	AC 220 - 240 V, 50/60 Hz, 1.5 KW	AC 220 - 240 V, 50/60 Hz, 1.8 KW
